09FW20

$2,417.45

Zebra TC78 Handheld Terminal – 1D, 2D – 5G, 4G, 3G – SE4770Scan Engine – Qualcomm 2.70 GHz – 4 GB RAM – 64 GB Flash – 6″ Full HD+ Touchscreen – LED – Front Camera – Rear Camera – Android Upgradable to Android 16 – Wireless LAN – Bluetooth – Rugged – TAA Compliant – IP65, IP68

+
  ... people are viewing this right now

ASCS Information
SKU: 09FW20
Documents
General Information
Manufacturer: Zebra Technologies Corporation
Manufacturer Part Number: TC78A13T1J4B1A10NA
Manufacturer Website Address: http://www.zebra.com
Brand Name: Zebra
Product Model: TC78
Product Name: TC78 Handheld Terminal
Marketing Information:

THE ULTRA-RUGGED MOBILE COMPUTER RE-IMAGINED FOR THE NEW AGE OF MOBILITY

Introducing the TC73/TC78, a new generation of mobile computers designed for a new generation of mobile solutions. Streaming video, video calls, intuitive multimedia-rich apps, augmented reality apps that enable new, more effective workflows – the rugged, thinner and lighter TC73/TC78 supports them all. More processing power for simultaneous app support. A 6-inch advanced display. More flexible battery options. Comprehensive wireless network support for unmatched performance and reliability – Wi-FiTM6E, 5G and CBRS1. Bluetooth 5.2 for superior accessory performance. The next level in scanning performance with the SE55 Advanced Range scan engine. Crystal clear voice on audio and video calls. Add the functionality of a workstation, two-way radio, RFID, PBX handset and an integrated mobile dimensioning solution. Mobility DNATMtools simplify every aspect of the TC73/TC78. And you get five years of product availability with 10 years of service and support. Step up to the TC73/TC78 – and step into the new world of mobility.

More rugged, lighter, thinner – and more ergonomic

Advanced manufacturing and materials technologies enable a more rugged design – without adding weight or thickness. It’s built to handle 10 ft./3.05 m drops to concrete and 2,000 consecutive tumbles. With IP65 and IP68 sealing, it’s dustproof and waterproof – submerge it in water and spray it down with a hose. Corning Gorilla Glass protects the display and imager window with maximum scratch-resistance and shatter-proofing – two of the most crucial and vulnerable features. The advanced industrial design and ergonomics bring superior comfort to practically any size hand, minimizing the effort required to hold and use these devices through exceptional balance, a grip area that is nearly 20% thinner and proper key placement and size.

Industry-leading 6-inch advanced display

More display space means less scrolling. The edge-to-edge display is 28% larger3, easy to view indoors and outside, works when wet and with a stylus or a finger – even with a glove.

All the right battery features and flexibility to stay powered up

Choose from four battery options: standard, extended capacity, wireless charge4and BLE, enabling device location with Device Tracker – even if the battery is depleted. All batteries are fast charging. The sealed battery compartment enables anywhere, anytime battery changes. Charge it with any standard USB-C charging cable. And PowerPrecision+ battery metrics make it easy to identify and remove unhealthy batteries from your battery pool.

LOADED WITH ALL THE LATEST TECHNOLOGIES

Blazing speed

Run simultaneous demanding applications with virtually instant response times with class-leading processing power, memory and storage. The next generation Qualcomm 6490 octa-core processor delivers 90% more processing power, a 400% faster graphics processor and locationing that is six times more accurate.2And up to 8 GB of RAM and 128 GB Flash, plus a 2 TB MicroSD card slot provides ample storage for the most data-intensive applications.

All the latest wireless connections

Give your workers the fastest speeds with Wi-Fi 6E, 5G and CBRS. Wi-Fi 6E is three times faster and supports four times the number of devices, all with less power. 5G brings wired speeds to wireless networks, plus better signal quality and strength. And support for CBRS private LTE networks4enables cost-effective wireless connectivity in the largest indoor and outdoor facilities.

Product Type: Handheld Terminal
Technical Information
Connectivity Technology: Wireless
Scanning Capability:

  • 1D
  • 2D

Scan Engine Model: SE4770
Image Sensor Type: Imager
Scanner Range: Standard Range
Wireless Charging: Yes
Sensor Type:

  • Light Sensor
  • Magnetometer
  • Gyroscope
  • Pressure Sensor
  • Proximity
  • Accelerometer

Multi-SIM Supported: Yes
Number of SIM Card Supported: 1
SIM Size Supported: Nano/eSIM
Features:

  • Gorilla Glass
  • Push-to-talk
  • Water Resistant

Drop Specification: Multiple 10 ft./3.05 m drops to concrete at room temp per MIL-STD 810H Multiple 8 ft./2.4 m drops to concrete over operating temp -20° C to 50° C per MIL-STD 810H

Processor & Chipset
Processor Manufacturer: Qualcomm
Processor Model: 6490
Processor Core: Octa-core (8 Core)
Processor Speed: 2.70 GHz
Memory
Standard Memory: 4 GB
Flash Memory: 64 GB
Display & Graphics
Screen Size: 6″
Screen Mode: Full HD+
Screen Resolution: 1080 x 2160
Display Screen Type: LED
Touchscreen Information
Touchscreen: Yes
Keyboard/Keypad
Buttons & Keys:

Programmable buttons for maximum flexibility: dual dedicated scan buttons; dedicated push-totalk button; volume up/down buttons and Trigger button of Trigger Handle via Back I/O

Network & Communication
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax
Bluetooth: Yes
Bluetooth Standard: Bluetooth 5.2
Cellular Data Connectivity Technology:

  • 5G
  • 4G
  • 3G

GPS: Yes
Global Navigation Satellite System (GNSS) Supported: BeiDou/Galileo/GLONASS
Interfaces/Ports
USB: Yes
USB Type-C: Yes
Camera
Front Camera: Yes
Front Camera Resolution: 8 Megapixel
Rear Camera: Yes
Rear Camera Resolution: 16 Megapixel
Software
Operating System: Android
Upgradable Operating System: Android 16
Power Description
Power Source: Battery
Battery Information
Battery Capacity: 4680 mAh
Battery Chemistry: Lithium Ion (Li-Ion)
Environmental Conditions
Operating Temperature: -4°F (-20°C) to 122°F (50°C)
Storage Temperature: -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing): 5% to 95%
Physical Characteristics
Form Factor: Phone-size
Rugged: Yes
Height: 7″
Width: 3.4″
Weight (With Battery): 12.31 oz
Miscellaneous
Package Contents:

  • TC78 Handheld Terminal
  • standard battery

Application/Usage:

  • Transportation
  • Logistics
  • Field Sales/Service
  • Warehouse
  • Distribution
  • Manufacturing
  • Government
  • Retail

Ingress Protection (IP) Rating:

  • IP65
  • IP68

Environmentally Friendly: Yes
Environmental Certification: RoHS
TAA Compliant: Yes
Warranty
Limited Warranty: 1 Year

Dimensions 3.4 × 7 in
