5CT439

Unstoppable performance for extended range 1D/2D barcode scanning

Every day, workers in your warehouse scan thousands of barcodes to ensure order accuracy and on-time delivery. Their productivity depends on the quality of the scanner you put in their hands. If your workers need to capture 1D and 2D barcodes near and far, with the corded DS3608-ER and cordless DS3678-ER scanner, you can give them the best – unmatched rugged design, unmatched scanning performance and unrivaled manageability. The advanced imager delivers lightning-fast capture of any 1D or 2D barcode displayed on a screen or printed on a label in virtually any condition, nearer and farther than any scanner in this class -from 3 in./7.6 cm to as far as 70 ft./.21.4 m away. The ultra-rugged design is practically indestructible – ideal for punishing environments. The DS3608-ER/DS3678-ER couldn’t be easier and less time-consuming to deploy and manage. And when it comes to cordless technology, the DS3678-ER is in a class of its own. The DS3608-ER/DS3678-ER – the unstoppable performance you need to maximize workforce productivity and throughput in your operations..

Superior scanning range
The advanced imager reads 1D and 2D barcodes printed on a label up to 60 percent closer and 35 percent farther than similar models in this class, with an extraordinary scanning range from 3 in. to 70 ft. (7.6 cm to 21.4 m). Now, one scanner can easily read barcodes on a picklist in hand and on the uppermost shelves of your warehouse racks, as well as extra-wide codes just a hands-length away – even if they are under shrinkwrap, damaged, dirty or poorly printed. The result? Workers can capture barcodes as fast as they can pull the trigger for first-time every time scanning – and extraordinary productivity.

Ultra-rugged – the most indestructible design in its class
The DS3608-ER/DS3678-ER is our most rugged scanner yet, with the highest drop, tumble and sealing specification in its class.The DS3608- R/DS3678-ER is built to survive an 8 ft./2.4 m drop to concrete – 23 percent more durable than any other scanner in this class. The DS3608-ER/ DS3678-ER operates reliably after 5,000 tumbles, simulating the real-world tumbling that occurs with a drop. Both models are dust proof, spray proof nd waterproofed to IP67 – they can be sprayed down with jetting water and even submersed in waterfor up to 30 minutes.

Easy management with our complimentary industry-best tools
Remotely configure scanners, upgrade firmware, format data properly for your back end and monitor PowerPrecision+ battery statistics and more with 123Scan 2 and Scanner Management Service (SMS).

Multi-code captures and processes up to 20 barcodes simultaneously
Many labels have multiple barcodes your workers need to capture. Now, one press of the trigger captures the right barcodes and applies the unique data format required for each one for instant transmission to your backend systems – all with complete control over the order barcodes are processed.

Faster pick-list processing
Users can easily select and capture an individual barcode from any pick list.

Ready for the freezer
The DS3608-ER and DS3678-ER are built from the ground up to handle extreme cold. Their unique plastics, cables and components are designed to handle freezing temperatures without becoming brittle- making these scanners ideal for use in freezers and outdoor yards.

A Bluetooth model in a class of its own for superior cordless freedom
Bluetooth 4.0 (Low Energy) provides lightning fast wireless communication and maximum energy efficiency.

Product Type: Barcode Scanner
Technical Information
Connectivity Technology: Cable
Scanning Capability:

• 1D
• 2D

Barcode Symbology Supported: 1D:

• Code 39
• Code 128
• Code 93
• Codabar/NW7
• Code 11
• MSI Plessey
• UPC/EAN
• I 2 of 5
• Korean 3 of 5
• GS1 DataBar
• Base 32 (Italian Pharma)

2D:

• PDF417
• Micro PDF417
• Composite Codes
• TLC-39
• Aztec
• DataMatrix
• MaxiCode
• QR Code
• Micro QR
• Chinese Sensible (Han Xin)
• Postal Codes

Digimarc

• Digital watermark technology

IUID Support:

• Supports IUID parsing, the ability to read and separate IUID fields per application requirements

Image Sensor Type: Imager
Physical Characteristics
Form Factor: Handheld
Product Color: Industrial Green
Height: 7.3″
Width: 3″
Depth: 5.2″
Weight (Approximate): 11.80 oz
Miscellaneous
Environmentally Friendly: Yes
TAA Compliant: Yes
Warranty
Limited Warranty: 36 Month
